1. Black electrophoretic paint on workpiece surface, no red rust in salt spray test for 96 hours

2. The working stroke of the slide rail is 140mm, 70mm forward and 70mm backward

3. No load sliding power of single slide track ≤ 2.5kGF

4. Grease cyP-B246 in the exercise area

5. Unlocking torque of single slide rail is 5N-M-8n-m

6. Torque of M6 bolt on locking plate assembly is greater than or equal to 10N-m

7. M8 bolt failure torque is greater than or equal to 25N-m, and pulling power is greater than or equal to 2000N

8. Slip gap:

The slide rail is fixed on the special test platform, and the relative position of the slide core and the slide shell is adjusted so that the slide core and the end of the slide shell are aligned. The measuring point is 10mm inward from the end of the slide shell, and 50N forces are applied to the front and rear end of the slide shell along the horizontal and upper directions. The left and right gaps are ≤0.60mm, the upper and lower gaps are ≤0.4mm, and the front and rear gaps are 0.35mm
